    Cable Stringing Equipment Hydraulic Cable Puller Winch 220KN Capacity

    Ask Lasest Price
    Brand Name : XINYA
    Model Number : SA-YQ220
    Payment Terms : L/C, T/T, Western Union, Western Union
    Supply Ability : 1 Set/Sets per Month
    Delivery Time : 60 days after payment
    Certification : ISO
    Price : get latest price
    MOQ : 1 set
    • Product Details
    • Company Profile

    Cable Stringing Equipment Hydraulic Cable Puller Winch 220KN Capacity

    Cable Stringing Equipment Hydraulic Cable Puller Winch 220KN Capacity


    Application

    SA-YQ220 Overhead stringing equipment hydraulic capstan winch cable puller is applicable to release wire, ground wire, cable in transmission line project.Together with tension machine, this model allows for the tension stringing of 220kV lines in mountainous and hilly areas and can be used for the traction stringing of OPGW or ADSS cable in various terrains.


    Features

    1.Infinitely variable speed and line control, the pull in the rope can be read on the line pull gauge.

    2.The max pull for conductor-stringing operation can preset,automatic overpull protection system.

    3.Spring applied hydraulic release brake acts automatically in case of hydraulic failure to ensure safety.

    4.Attached reel winder with automatically level wind.load and unload conveniently.

    5.Hydraulic pullrope pinch device,replacing reel conveniently.


    Main Specifications

    ModelSA-YQ220 Hydraulic Puller
    Maximum Traction Force (kN)220
    Continuous Tractive Effort (kN)180
    Maximum Pulling Speed (km/h)5
    Bullwheel Bottom of Groove Diameter (mm)Φ760
    Number of Bullwheel Grooves10
    Maximum Diameter of Suitable Steel Rope (mm)Φ30
    Maximum Through Connector Diameter (mm)Φ75
    Engine Power / Speed (kW/rpm)243/2100
    Dimensions (mm)5700× 2300× 2600
    Weight (kg)8000

    Main Components

    EngineCummins (USA) water-cooled diesel engine
    Main Variable Displacement Pump, Main MotorRexroth (BOSCH)
    ReducerRexroth (BOSCH)
    Main Hydraulic ValvesRexroth (BOSCH)
    RadiatorAKG
    Hydraulic Instrument
    Suitable DrumModel GSP1600 (Item number: 07125D)
